ASTM A501 Carbon Steel Pipe

Size:20*20-500*500mm
Thickness:1.3-40mm
Length:5.8m/6m/12m

Send Inquiry

Download

Description

Product Specification

Size	2020-500500mm
Thickness	1.3-40mm
Length	5.8m/6m/12m
Technique	Hot-formed
Steel grades	ASTM A500, ASTM A501,Q235,Q355
Application	Shipbuilding Overground piping Steel Structures i.e. Airports, Facotry Workshop, Metro Station, etc.
Package	in the bundle, or wrapped with waterproof cloth as per the customers' requirement
Delivery Time	10 days if stock is available; 25 days for new production
Loading Port	Xingang, Tianjin, China
MOQ	10 tons
1. All the pipes are high-frequency welded. 2. Both inner and outer welded stabs can be removed. 3. Pipe can be necked down and punched holes. 4. Supplying BV or SGS Inspection if the client needs it.

ASTM A501 Carbon Steel pipe

ASTM A501 Carbon Steel pipe1

ASTM A501 Carbon Steel pipe2

ASTM A501 is a standard specification for hot-formed welded and seamless carbon steel structural tubing. It is commonly used for structural applications such as bridges, buildings, and other infrastructure projects. The yield strength of ASTM A501 carbon steel pipe is 36,000 PSI and its minimum tensile strength is 58,000 PSI.

The equivalent material for ASTM A501 carbon steel pipe can include the following:

- API 5L Grade B

- ASTM A53 Grade B

- ASTM A106 Grade B

The chemical composition of ASTM A501 carbon steel pipe includes the following elements:

- Carbon (max): 0.26%

- Manganese: 0.60-1.20%

- Phosphorus (max): 0.035%

- Sulfur (max): 0.035%

In addition, ASTM A501 carbon steel pipe can also have trace amounts of other elements such as silicon, copper, and nickel.

It is important to note that ASTM A501 carbon steel pipe is not intended for pressure applications, as it is designed for structural purposes only. It is also important to follow proper welding and fabrication procedures when working with this type of pipe to ensure its structural integrity.
