What Is The Function Of Steel Pipe Piles?

1. What is the function of steel pipe piles?

(1) What is a steel pipe column

Steel pipe piles are composed of steel pipes, tongue and groove mortise, and tenon pins. The left end of the steel pipe diameter is vertically connected to the tongue and groove groove. The cross-section of the tongue and groove is a square frame with one side open. Reinforcement ribs are provided on the side of the tongue and groove groove. The right end of the steel pipe diameter is vertically connected to the tongue and groove pin at the radial position. The groove section of the tongue and groove pin is I-shaped.

(2) Function of steel pipe column

When the utility model is used in the cofferdam, the steel pipe piles overlap each other in an arc or circular shape. It can play the role of surrounding water, soil, sand, etc. The tongue and groove steel pipe pile of the utility model has the advantages of novel design, simple structure, convenient use, easy overlap, and good sealing. It includes non-circular cross-sectional profiles, equal wall thickness, variable wall thickness, variable diameter and variable wall thickness along the length direction, symmetrical and asymmetrical cross-sections, etc. Such as square, rectangular, conical, trapezoidal, spiral pipes, etc.

2. Characteristics of steel pipe columns

(1) Various specifications:



There are many choices. At present, the standard production of steel pipe piles on the market has a variety of specifications. In terms of diameter, the maximum is 2500mil and the minimum is 316mm. In terms of wall thickness, the maximum is 25mil and the minimum is 6.5mm. During construction, the most suitable application can be selected from a variety of specifications based on the actual stress conditions, so that the strength of the steel pipe column can be fully utilized to meet the project's requirements for safety and economy.

(2) Strong bearing capacity:



At present, the steel pipe columns used in engineering construction are mostly low-carbon steel. This material has strong shear strength, tensile strength, compression resistance, and other aspects. After being processed into steel pipes, it has a high level of bending resistance and is suitable for use in geological environments with strong bearing layers, so that its stress characteristics can be fully utilized to optimize the bearing capacity of a single pile, reduce the size of the foundation pedestal, and reduce the total amount of piles.

(3) Easy to adjust the pile length:

Improve economic benefits. The conventional length of each section of the steel pipe column is 6m, which can be extended by welding. If the buried depth of the bearing layer changes, the steel pipe pile can be welded or cut according to the pile sinking situation. In addition, the part cut out of the steel pipe column can also be used in welding other steel pipe columns, avoiding the waste of resources. It can also accurately control the design elevation of the pile top, which is conducive to the construction work.
