Ground Pile

Product Details:

A spiral ground pile is a ground bored pile with spiral characteristics, including a drill bit/drill pipe/spiral blade and a connecting pipe. The drill pipe is connected to a power input connector. It is convenient to drive the pile into the ground and use it directly as the pile body. The spiral ground pile can penetrate and compact the soil around the pile hole, increasing the lateral friction resistance of the soil around the pile, making the pile foundation have strong bearing capacity, pullout resistance, horizontal resistance, small deformation, and good stability.

Features of spiral ground piles:

1. Different materials should be selected according to the environment and customer needs. The steel should be made of materials produced by large steel companies, and recycled steel should not be used. To achieve high-quality indicators, strict quality control is implemented.

2. Specially designed products have been tested by mechanics, software simulation, and third-party testing, and their mechanical properties are guaranteed. Following strict guidelines, static load tests, compression tests, tensile tests, and lateral pressure tests were conducted to evaluate the product's compressive resistance, stability, and durability.

3. Compatibility with structure: Different bolts are used for piling according to different needs of customers. There is no need to damage the surrounding environment, no need to dig the ground, and no need to pour cement. The spiral piles are directly driven into the ground, which greatly reduces the cost.

4. Environmental protection, recycling, no corruption, zero cleaning cost. Migration is simple and fast, and it is possible to migrate anytime and anywhere, reducing the impact on the environment and minimizing migration costs.

5. Suitable for all soils, no matter what kind of soil (from clay to rock), you can find suitable anchor piles. The installation is simple, convenient, and fast, and no on-site welding or processing is required. Each machine can install up to 200 bolts per day.

6. High-precision positioning vertically into the ground, positioning accuracy is 1.5cm

Operating conditions:

1. Complete geological data, construction drawings, and construction organization design.

2. Ground and underground obstacles within the construction site have been eliminated or dealt with. The site has been leveled, weak sites affecting the operation of construction machinery have been properly dealt with, and drainage measures have been taken.

3. Water, electricity, roads, and temporary construction facilities are ready.

4. The measurement baseline and horizontal base points have been set up on-site and protected.

5. When constructing complex soil layers, test piles should be carried out in advance, and the number is generally not less than 2.

Production technology:

The raw material for producing spiral grounding piles is the Q235 welded pipe. Generally, qualified ground piles can be produced through cutting, deformation, welding, pickling, and hot-dip galvanizing. Pickling and hot-dip galvanizing are important anti-corrosion treatment processes that affect spiral ground piles' service life. The spiral pile's processing level directly determines the metal pile's service life. For example, whether the selected welded pipe has blisters, whether there are false welds, and the width of the weld will affect the future service life of the pile and the quality of subsequent processing. Pickling is an important basic anti-corrosion process. The time of hot-dip galvanizing and the thickness of the surface galvanizing layer will affect the quality of the anti-corrosion treatment of piles. Generally speaking, screw piles can be used for 20-30 years. The environment and method of use also affect the service life of the pile, such as the pH of the soil and whether the operation process is appropriate. Improper use will cause damage to the surface of the metal pile, damage to the metal protective layer, accelerated corrosion of the metal pile, and reduced service life.

Scope of application:

1. In-line spiral ground stakes are used in gardens or lawns.

2. Inline spiral ground piles should be suitable for soft soil or sandy soil.

3. Large-scale in-line spiral ground piles are used in solar photovoltaic projects.

4. U-shaped spiral ground piles are used for fences and fences.

5. Spiral ground stakes are used to fix tents, mobile homes, greenhouses, flagpoles, guardrails, fences, etc. And can be reused for a long time.

Our factory:
