Glass Curtain Wall Steel Pipe

Size Square:20x20-1000x1000mm
Rectangular:20x30-700x800mm
Thickness:1-40mm Length:5.8m/6m/12m

Send Inquiry

Description

The glass curtain wall steel pipe system includes a beam and a column, the beam is a square steel pipe, and the column is a rectangular steel tube; the column and the beam are mechanically connected by a connector installed with a spring screw. The column and the beam are connected without welding, and there is no welding deformation. The system has the characteristics of a beautiful appearance, low cost, high strength, rigidity, and convenient construction.

Product Specification

Size	Square:20 x 20 -1000 x 1000 mm Rectangular: 20 x 30 -700 x 800 mm
Thickness	1-40mm
Length	5.8m/6m/12m
Technique	ERW
Material Grade	Q195,Q215,Q235B,Q355B, S235JR/S235/S355JR/S355
Application	the glass curtain wall system, steel structure project, etc
Package	in the bundle, or wrapped with waterproof cloth as per the customers' requirement
Delivery Time	5-10 days for the stock, 20-25 days for production
Loading Port	Xingang, Tianjin, China
MOQ	5-10 tons
All the pipes are high-frequency welded. Supplying BV or SGS Inspection if the client needs.

Glass curtain wall steel pipes are an essential component of modern high-rise buildings. These pipes are used as structural support for the glass curtain wall system, which is an outer covering of a building that consists of glass panels and metal frames. The steel pipes are usually installed vertically and horizontally, forming a grid-like structure that supports the weight of the glass panels and provides the building with its iconic appearance.

Glass curtain wall steel pipes are made of high-quality steel with a high level of strength and durability. The pipes are designed to withstand the wind load and other external forces that are typically encountered in high-rise buildings. They are also corrosion-resistant and can withstand extreme temperatures.

The installation of glass curtain wall steel pipes requires careful planning and precision engineering to ensure that they are installed correctly and can support the weight of the glass panels. The pipes must also be able to accommodate thermal expansion and contraction, which can occur due to changes in temperature.
